Bell 206 V3 GPS Stabilized 6CH RC Helicopter

Product Overview

The Bell 206 is a family of two-bladed, single- and twin-engined helicopters, originally designed for the United States Army's Light Observation Helicopter program. Although it was not selected by the Army, Bell successfully redesigned and marketed the aircraft commercially as the Bell 206A JetRanger. Now available in a scaled RC version with cutting-edge GPS stabilization, experience the thrill of precise flying with advanced features and reliable performance.

Product Features

• High-precision remote control with a range of up to 1 km.
• One-key return and low-power return for added safety.
• M10N GPS system for stable flight and easy hovering.
• Auto mode with circular flight capabilities.
• Modular design for easy maintenance and quick battery replacement.
• Tail high-speed brushless motor for enhanced performance.

Specifications

Feature	Specification
Length (without blades)	720mm
Height	235mm
Width	150mm
Weight (exclude battery)	869g
Main rotor diameter	810mm
Main rotor length (one)	370mm
Tail rotor diameter	125mm
Gear specification	Motor main gear: 13T, Main drive gear: 81T, Tail drive motor: Brushless motor
Motor	3508 Brushless motor
ESC	60A
Flight mode	GPS Mode, 3D Manual Mode, Low voltage return, Semi-automatic assisted flight
Satellite positioning module	GPS/GLONASS/Galileo
Hovering precision	Level: ±1.5m, Vertical: ±0.5m (when GPS is working well)

Flight Experience

The Bell 206 V3 is equipped with the latest M10N positioning system and a high-precision IMU for attitude calculation. The barometer ensures smooth hovering and flight, making it easier to control, even for beginners. Experience the flight precision similar to drones with effortless hovering and automatic flight mode.

Safety Features

This model includes one-key return and low voltage return for safer flights. If the power reaches a low set value, the helicopter will automatically return to its takeoff point and land safely, provided there is enough reserved power.

Power Configuration

Equipped with a 16V brushless motor and optimized ESC, this model provides greater flight efficiency and an impressive flight time of over 20 minutes.
